GB/T 41486-2022 in English
VALIDCorrugated metal hose assemblies for domestic drinking water pipes
- Issued on:2022-04-15
- Implemented on:2022-11-01
- File Format:PDF
- Delivery:Via email within 1~3 business days
$272.00
《GB/T 41486-2022生活饮用水管道用波纹金属软管》由TC237（全国管路附件标准化技术委员会）归口，TC237SC1（全国管路附件标准化技术委员会柔性管分会）执行，主管部门为中国机械工业联合会。
Introduction
Core technical specifications of metal hoses
Material selection indicators
The bellows in contact with drinking water must be made of S30408/06Cr19Ni10 stainless steel. The tensile strength of the mesh material must not be less than 520MPa, and the flange gasket must comply with food-grade rubber hygiene standards.
Key performance tests
| Nominal size (DN) | Minimum bending radius (cm) | Withstand pressure test value (MPa) |
|---|---|---|
| 50-100 | 20 | 2.4 |
| 200-400 | 35 | 4.8 |
Quality inspection system
- 3D optical scanner reverse inspection of corrugation geometric accuracy
- Helium mass spectrometer leak detector achieves <1×10⁻⁶Pa·m³/s level sealing detection
For example, Hangzhou Water Affairs used this project detection system in the old city renovation, and the product life cycle was extended by 42%
Anti-corrosion construction points
When wrapping the anti-corrosion mineral fat tape on site, the actual measured force must reach 15-20N, and the vote482 thickness gauge is used to ensure that the cumulative thickness of the double-layer protection is ≥2.8mm.
Beijing Tongzhou Case
Successfully compensated for 35mm axial displacement when dealing with surface settlement, proving that the four design pressure redundancy factors meet the 1.5 times safety requirement.
Loading PDF document...
Error loading PDF. Please make sure the file is valid and try again.
