GB/T 16709.1-2010 in English

《GB/T 16709.1-2010真空技术 管路配件的装配尺寸 第1部分：非刀口法兰型》由TC18（全国真空技术标准化技术委员会）归口，主管部门为中国机械工业联合会。

Vacuum Technology — Mounting Dimensions of Pipeline Fittings — Part 1: Non Knife-edge Flange Type

1 Scope

This part of GB/T 16709 specifies mounting dimensions for vacuum pipeline fittings (elbows, tees and crosses) of non-bakable and non knife-edge flange for nominal bores from 10 mm to 250 mm of the R5 series.

2 Normative References

The following documents contain provisions which, through reference in this text, constitute provisions of this part of GB/T 16709. For dated references, subsequent amendments (excluding corrections), or revisions, of any of these publications do not apply to this part. However, parties to agreements based on this part are encouraged to investigate the possibility of applying the most recent editions of the normative documents indicated below. For undated references, the latest edition of the normative document referred to applies.

GB/T 4982 Vacuum Technology — Quick Release Couplings — Dimensions — Part 1: Clamped Type (GB/T 4982-2003, ISO 2861-1:1974, IDT)
GB/T 6070 Vacuum Technology — Flange Dimensions (GB/T 6070-2007, ISO 1609:1986, MOD)

3 Terms and Definitions

For the purposes of this part, the terms and definitions given in GB/T 4982 and GB/T 6070 apply.

4 Requirements

4.1 Mounting dimensions of the vacuum pipeline fittings shall be as specified in Table 1. See Figures 1 to 3.

4.2 Flange dimensions shall be as specified in GB/T 4982 and GB/T 6070. Flange specified in GB/T 6070 should be rotatable.

4.3 Bolt holes in the flanges specified in GB/T 6070 shall be positioned as shown in Figure 4. Angle α is a function of the number of bolt holes.

Foreword II
1 Scope
2 Normative References
3 Terms and Definitions
4 Requirements
Bibliography
