GB/T 40887.1-2021 in English
VALIDWheelchair containment and occupant retention systems for accessible transport vehicles designed for use by both sitting and standing passengers—Part 1:Systems for rearward-facing wheelchair seated passengers
- Issued on:2021-11-26
- Implemented on:2021-11-26
- File Format:PDF
- Delivery:Via email within 5 business days
$359.00
| Standard No: | GB/T 40887.1-2021 |
| Document status: | VALID |
| Title in English: | Wheelchair containment and occupant retention systems for accessible transport vehicles designed for use by both sitting and standing passengers—Part 1:Systems for rearward-facing wheelchair seated passengers |
| Title in Chinese: | 无障碍客车的轮椅车及乘坐者限位系统 第1部分：后向式轮椅车乘坐者系统 |
| Language: | English |
| File Format: | Electronic (PDF) |
| Delivery: | Via email within 5 business days |
| Issued on: | 2021-11-26 |
| Implemented on: | 2021-11-26 |
| ICS Classification: | 11.180-Aids for disabled or handicapped persons |
| Chinese Classification: | C30-Medical apparatus and devices in general |
| Professional Classification: | GB-National Standard |
| Related Keywords: | 0.65-0.8 performance test requirements wheelchair
wheelchair containment rearward-facing wheelchair rear-facing wheelchair wheelchair width |
| Related Topics: | wheelchair
GB/T 40887.1 GB/T 40887.1-2021 Unmanned wheel wheelchair Quality requirements for wheelchair seat cushions |
《GB/T 40887.1-2021无障碍客车的轮椅车及乘坐者限位系统 第1部分：后向式轮椅车乘坐者系统》由TC148（全国残疾人康复和专用设备标准化技术委员会）归口，主管部门为民政部。
Introduction
Analysis of the core content of the standard
This standard is equivalent to the ISO108651:2012 international standard, which specifies the technical requirements for the rear-facing wheelchair occupant system (RF-WPS), and is applicable to barrier-free passenger vehicles for passengers weighing more than 22kg.
Key Design Elements
| Component Type | Functional Requirements | Dimensional Specifications |
|---|---|---|
| Forward Shift Barrier (FEB) | Limits forward movement of the wheelchair | Width 250-280mm, height ≥1400mm |
| Side Shift Barrier (LEB) | Prevents lateral tilting/sliding | Adjustable component displacement ≤15mm |
| Floor Surface | Provide sufficient friction | Friction coefficient 0.65-0.8 |
Performance test requirements
Wheelchair limit test
Use a surrogate wheelchair (SWC) to load a 75kg dummy for dynamic test, requirements:
- Lateral tilt angle ≤10°
- Displacement in all directions ≤50mm
- Rotation deviation ≤15°
Barrier static load test
| Test type | Load requirement | Deformation limit |
|---|---|---|
| FEB strength | 9.6kN | Permanent deformation ≤15mm |
| LEB strength | 1.6kN | No sharp structure |
Implementation suggestions
Special attention should be paid during the design phase:
- FEB should be covered with impact-absorbing material in accordance with FMVSS201/ECE R21 requirements
- The rounding radius of all components should be ≥2mm to eliminate the risk of sharp edges
- The stop request button area should be set within the horizontal range of 600-900mm
Key points for test verification:
- Both manual wheelchairs and mobility scooters need to be tested
- The static load test duration is not less than 1.5 seconds
- The friction coefficient test is carried out in accordance with ISO717613
