YD/T 3880-2021 in English
VALIDTechnical requirements of services for new generic top level domain: format and content for registry operator monthly reporting
- Issued on:2021-05-17
- Implemented on:2021-07-01
- File Format:PDF
- Delivery:Via email within 1~3 business days
$156.00
| Standard No: | YD/T 3880-2021 |
| Document status: | VALID |
| Title in English: | Technical requirements of services for new generic top level domain: format and content for registry operator monthly reporting |
| Title in Chinese: | 互联网新通用顶级域名服务 注册局运行月报规范技术要求 |
| Language: | English |
| File Format: | Electronic (PDF) |
| Delivery: | Via email within 1~3 business days |
| Issued on: | 2021-05-17 |
| Implemented on: | 2021-07-01 |
| Professional Classification: | YD-Telecommunication |
| Related Keywords: | new generic top level domain
new generic top-level domain .idn domain name global domain name system temporary domain names |
| Related Topics: | Operating Bureau
LAN server Sign up at the end of September top technology domain name top TLD YD/T 5167-2021 Specification requirements for overhead crane operating warning lights yd/t202408-2021 |
本文件规定了域名注册局定期向ICANN（互联网名称与数字地址分配机构）报送的注册数据的内容和格式，包括：数据分类、数据项定义、处理流程、算法、技术接口等。基于本文件，注册局可以对新通用顶级域下的注册商注册交易及注册局注册活动进行统计处理，实现每月报送功能。
本文件适用于搭建同时符合ICANN技术规范和工信部域名管理办法的新通用顶级域名系统。
Introduction
Standard Background and Evolution
Since ICANN opened new generic top-level domain (gTLD) applications in 2012, the global domain name system has entered a diversified development stage. As an important part of a series of technical specifications, this standard aims to unify the format and content requirements for the monthly operational data submitted by registries to ICANN. Its technological evolution presents three notable features:
- Data granularity is refined: from early simple statistics to 41 transaction indicators and 39 activity indicators
- Timeliness is strengthened: the UTC time cutoff data at the end of the month is explicitly required
- Technical interface standardization: using HTTPS protocol to interact with specific API endpoints
Interpretation of core data specifications
5.1 Key fields of transaction reports
| Field category | Typical fields | Statistical logic |
|---|---|---|
| Domain name life cycle | net-adds-*yr/net-renews-*yr | Statistics are classified by 1-10 years, and pendingCreate status needs to be excluded |
| Domain transfer | transfer-gaining-successful | Data for the month when the grace period ends |
| Dispute settlement | transfer-dispute-won | The month of the ruling is the statistical point |
5.2 File format requirements
Actual case: The transaction report file of a .idn domain name should be named xn--fiq228c-transactions-202306.csv, where:
- IDN must be converted using Punycode
- The date format strictly follows YYYYMM
- The line break uses CRLF(
Registry Activity Monitoring Indicators
| Monitoring Dimensions | Key Indicators | Technical Description |
|---|---|---|
| Registrar Management | operational-registrars | Distinguish between three statuses: operational/ramp-up/preparatory |
| Query Service | whois-43-queries | Port 43 and Web query volume need to be counted separately |
| DNS response | dns-udp-queries-responded | Distinguish between UDP and TCP transport protocols |
Implementation recommendations
Best practices for data collection
- Establish a EPP server log analysis pipeline to automatically extract srs-dom-* series indicators
- Implement a double verification mechanism for the net-adds field and compare registration transaction records with DNS zone files
- Deploy UTC time synchronization service to ensure data consistency at the end of the month
Frequently Asked Questions
- Avoid counting temporary domain names in pendingCreate status into total-domains
- AGP exemption requests (agp-exemptions-granted) need to be associated with specific domain name records
- Shared registration systems need to clarify data ownership rules
